TADS are effective in reinforcing anchorage: A new trial

By on December 10, 2018 in Recent posts with 1 Comment
TADS are effective in reinforcing anchorage: A new trial

This post is about a new trial that gives us useful information on temporary anchorage devices in reinforcing anchorage. I thought that the findings were interesting and clinically relevant.

Anchorage control is critical to achieving orthodontic goals. Temporary Anchorage Devices (TADs) have revolutionised anchorage control. Recent trials and systematic reviews have illustrated that they are effective. I feel that this new trial adds to our information on this relatively new orthodontic technique.  A team from Malmo, Sweden did this study. The American Journal of Orthodontics published it. I thought that it was great that this was an open access paper.

Anchorage reinforcement with miniscrews and molar blocks in adolescents: A randomised controlled trial

Niels Ganzer, Ingalill Feldmann, and Lars Bondemark: Am J Orthod Dentofacial Orthop 2018;154:758-67


This is the main report on this trial. I have posted about their other paper looking at cost-effectiveness before.

What did they ask?

They asked the following question:

“Do TADs deliver better anchorage capacity than blocks of molar teeth”?

They looked at this by doing a trial. The PICO was

Participants: Orthodontic patients aged 11-19 years who needed treatment with extractions of maxillary first premolars and anchorage reinforcement. They defined this as approx 75% retraction of anterior teeth during space closure.

Intervention: Temporary Anchorage Device with space closure using Ni-Ti springs at 150g force.

Control: Molar block formed from tying the upper second molar to the second premolar.  Space closure was done with active tie-backs using 150g force.

Outcome: Loss of anchorage during levelling and alignment and during space closure.

This was a clinically relevant trial design. It is worth me pointing out that the two interventions used different methods of applying force during space closure. I shall return to this later.

They did a good sample size calculation, sealed envelope randomisation and allocation concealment.

The data was collected from scanned study casts taken at the start of treatment (T1), at the end of levelling and alignment (T2) and after space closure (T3). The sequential scans were superimposed on the palate. They then measured molar tooth movement, rotations, tip and torque.

What did they find?

80 participants took part in the trial. 7 dropped out in the TADs group, and 2 of the molar block patients did not complete the study.

I will only review the data on loss of anchorage. I have put this into this table.

Treatment phaseTADsMolar blockDifference (95% CI)P
Levelling and alignment1.21.40.1 (-0.2, 0.5)0.49
Space closure0.22.42.2 (1.7-2.8)0.001

They also reported that there were no differences in the treatment time between the groups. The alignment and levelling phase took 10.5 months for the TAD group and 9.3 months for the molar blocks. Whereas, the space closure took 8.9 months for TADs and 9.0 months for the molar block group.

They concluded;

“Miniscrews provided increased anchorage capacity over molar blocks. This was mostly during the space closure phase of treatment”.

What did I think?

They did a nice trial with a sufficient number of patients, and they answered a clinically relevant question. Their methods were excellent, and the study was carried out well with only a few dropouts.  As usual, there are several matters that we need to consider when we interpret the results. Firstly, there was an unequal number of dropouts, with more participants leaving the trial in the TADs group.  Most of these differences were due to loss to follow up from poor impressions and discontinuing treatment. Nevertheless, they did an intention to treat analysis that may reduce any bias due to completion rate differences.

I was a little concerned to see that they used NiTi springs for the TADs group and active ligatures for the molar block patients. They pointed out that these interventions generated the same level of force. Importantly, we know that active ligatures suffer from greater “force fade” than NiTi springs. However, other trials have shown no differences in space closure rate between these two methods. The authors have also used treatment mechanics that they would typically use. Nevertheless, we must assume that there may be a difference in tooth movement between the two interventions. As a result, you need to decide whether this influences your interpretation of the study.

My feeling is that this is another study that illustrates the effectiveness of TADs and reinforces the finding that we get about 2mm anchorage reinforcement with this treatment method. But I wished that they had used NiTi springs for both groups.

Now you have read this blog ( New Update)

Your country is United States so currency auto changed to US Dollars

Your response to my plea for donations has been fantastic. We have hit the target for the new website, fast servers and general support.  I will leave the donate button open if anyone wants to make a further donation for ongoing support.

I now have a small favour to ask . . . I started this blog three years ago, and I had no idea that it would be so popular.  It has been read 0.5 million times this year.

I have tried to make this blog educational and to challenge claims that are made about treatments. My posts are entirely free from commercial bias and are not influenced by societies, politicians or any other people with vested interests. I have also made the blog open to everyone.

Since starting the blog, I have written the website myself and have funded hosting, security and backups for which I have used speaking fees.

Now I am facing a problem: because of the increasing number of readers I need to pay for a new, professionally written website, faster hosting and better security. I have also decided to reduce my speaking commitments. As a result, I need to attract funds to support the costs of this blog.

I have rejected charging readers and taking advertising. The only remaining method of raising these funds is to ask for donations.  In short, I need to raise £15,000 to keep the blog going for the next five years. The donation button below takes you through to a secure PayPal account.

If everyone who has an interest in my blog helps to support it by making a modest donation, the future of this blog will be certain.

The current exchange rate is 1.00 GBP equals 1.29 USD.
Personal Info

Donation Total: $6.43



Tags: , , , , , , , ,

There is 1 Comment

Trackback URL | Comments RSS Feed

  1. DW says:

    I have been working with TAD supported anchorage for my Mx 4s exo cases, and while space closure time does not decrease, my overall treatment time has been shortened by 7 months on average because I don’t have to correct the resultant CII component of Mx molar anchorage lost. This also means less Md incisor proclination. I am a fan.
