Is overjet reduction influenced by the duration of functional appliance wear?

By on February 6, 2017 in Recent posts with 13 Comments
Is overjet reduction influenced by the duration of functional appliance wear?

Is overjet reduction influenced by the duration of functional appliance wear?

We all think that the effectiveness of removable functional appliances is influenced by the amount of time that our patients wear their appliances. This post is about a new study that answers this question.

Overjet reduction in relation to wear time with the van Beek activator combined with a microsensor

Ali S.A. Al-Kurwi,, Annemieke Bos, Reinder B. Kuitert

AJO-DDO 151, Issue 2, 277–283

When intra oral timing devices were developed I thought that they would be useful in research projects. As a result, it was great to find this interesting paper in the American Journal of Orthodontics.

A team from Amsterdam, the Netherlands did this very interesting research project.

What did they do?

They did the study to find if there was an association between overjet change, duration of wear and length of functional appliance treatment.

This was a prospective cohort study of 28 adolescent patients who had overjets of at least 6 mm. The residents in the Department treated the patients with a van Beek activator. This is a headgear/activator combination method of treatment.

They fitted a TheraMon timing device to record the duration of functional appliance wear. They told the patients and the parents that they were measuring their cooperation.

The TheraMon sensor is a small device which is embedded in the removable appliance. The sensor works by  recording  the time that its surrounding temperature is more than 35°C. This corresponds to the wear time of the appliance. The orthodontist reads the data using a special readout station.

They used standard van Beek activators with headgear, and asked the patients to wear their appliances for at least 12 hours a day.

They evaluated the progress of treatment for the first three appointments which covered a period between 3.6 months and 9.3 months. At each appointment they measured the overjet with a ruler and the duration of appliance wear with the Theramon.

They calculated the amount of overjet reduction as percentage change between recordings.


What did they find?

I have put the relevant data in this table below.

Percentage reduction in Overjet (median)

Time period< 8 hours wear>8 hours wearP
T1-T06.2512.50.32
T2-T110.525.40.004
T3-T211.220.000.05
T3-T127.250.000.004

It was interesting to see that the patients wore their appliances between 0.49 and 11.03 hours per day.

They also found an association between wear time and percentage reduction in overjet.  For example, wear times of eight hours or more was associated with greater overjet reduction. Importantly, the patients who wore their appliance more than eight hours a day achieved an overjet reduction of 50% compared to 20% when they wore it less than eight hours.

I thought it was also interesting to see that patients with a daily where time of 11 hours or more a day had overjet reductions of 6.5 mm. Those who only wore their appliance for 1.8 hours or less had overjet reductions of only 1.0mm

What did I think?

This was very interesting observational study.  I thought that there were several important findings..

Firstly, the patients did not wear their appliances for the length of time that the operators asked them  (at least 12 hours per day). In effect, they did not do what the orthodontists asked! However, if they wore the appliance for more than eight hours a day they still achieved satisfactory overjet reduction.

It was also interesting to find that even though the patients knew they were being monitored none of them achieved the target time of 12 hours a day.

As usual, I would like to consider the effects of this paper on clinical practice. Importantly, it provides interesting information on the time that we ask our patients to wear their functional appliance.  For example, I ask my Twin Block patients to wear their appliances for 24 hours a day, apart from when they were eating. I wonder if this study shows that we only need to ask our patients to wear their appliances for 12 hours a day? This would mean that they would not have to wear their Twin Blocks when they are at school.  This may boost our success rates.

This also showed that if when the patients wore the appliance for less than eight hours, the appliance did not work. This makes me think that if a patient is wearing the appliance for less than eight hours, according to the timing device, then we should consider another treatment.

In summary, I thought this was a really interesting study that answered fundamental clinical questions. These findings would persuade me to start using timers for my removable functional appliances.
